Dini Argeo 3590EXT series User Manual

3590EKR, 3590EXP, 3590EXT, CPWE, CPWET series indicator E-AF09_02_13.01_EN_U
10
Figure 4
–
Measurements and dimensions in mm
1/2) Available for load cells / serial lines / inputs / outputs
3) Power supply input.
4) RJ45 connector
3.3 CPWET CASE AND DIMENSIONS
The weight indicator has a STAINLESS STEEL case, whose external dimensions are shown in the figure 4. The instrument
may be installed on the wall.
NOTE: If the identification plate is supplied separately (therefore not attached to the indicator), it is advisable to
attach it to the indicator, in order to be able to identify the instrument.
1
2
3
4
