DINKING DK3300i - Technical Specifications; Engine Specifications; Generator Configuration Details

24
XI. Technical Parameters
Item Parameter
enignE
Engine model 148F/P-2 164F/P
Engine type
Single-cylinder, four-stroke, air-cooled, overhead valve,
tilted 25º of the center of gasoline engine cylinder
Bore size × Stroke (mm) 48.6×43 64×45
Displacement (cc)
79.7
145
Compression ratio 8.7± 0.2 8.7± 0.2
Gas distribution mode OHV OHV
Cooling mode Forced cooling wind Forced cooling wind
Output power (kW/r/min) 2.1/4500 3.8/4650
Starting method Recoil start
Fuel tank volume (L) 4L 3.7L
Fuel type and grade Vehicle-use unleaded gasoline
Lubricating oil capacity 0.35 0.45
Lubricating oil model SAE 10W /30 SAE 10W /30
Lubrication mode Splash lubrication Splash lubrication
Noise dB (at 7m) 62 63
rotareneG
Rated power (kW) 1.8 2.8
Rated voltage (V) 100/120/230 100/120/230
Rated frequency (Hz) 50/60/50&60 50/60/50&60
Rated power factor 1 1
Phase number Single phase Single phase
DC output 12V 8.3A 12V 8.3A
noitarugifnoC
Motor Brushless (permanent magnet)
Voltage regulation Inverter regulation
Frequency regulation Inverter regulation
Overall dimension (mm) 480x290x430 480x290x430
Net weight (kg) 18 21
