4. Secure the bracket and hood hinge using the
factory bolts, ensuring the hood hinge lines
up with the tape.
5. Remove the tape and repeat the steps on the other
side to complete the installation.
NOTE: On the passenger side of the vehicle, remove
the washer uid line before removing the hood hinge
bolts. Then reinstall the washer uid line after
bracket installation is complete.
6. Once the brackets are mounted to the hood, refer to
the Universal Bracket Info/Mounting Guide, to mount
your pods onto the bracket.
A small cutout has been designed on each bracket to
aid in wire routing. Use the included zip-ties to secure
the wiring away from the hood hinge.
NOTE: Do not use automatic car washes with this kit installed.
Scan the QR code to link to our installation video online!
NEED MORE HELP?
We’ve taken the time to test our products on your vehicle. We can
guarantee compatibility and tment the rst time – no guessing
game! If you need more help with installation, watch our step-by-step
video to walk you through the process.
WARRANTY
3 YEAR
This installation guide is for the following SKUs:
