Diono Cambria - Backless Booster Seat

18
Backless Booster Seat
While this booster seat is designed to oer reinforced side-impact protection with its
backrest section attached, the seat bottom can also be used alone as a backless booster.
1) Remove seat bottom from backrest section (see page 11).
2) Disengage the two middle elastic straps and unfold padded
fabric ap on back of seat bottom.
A
3) Make sure booster seat is correctly installed (see pages 13–14)
and properly positioned on vehicle seat.
4) Properly position child: sitting upright and all the way back
in the booster seat.
5) The child’s head must be supported by the vehicle
headrest or vehicle seat back in high back booster or
backless booster mode
6) Fasten seatbelt across child.
7) Make sure seat belt is not twisted and lays at across
child’s hips, torso and shoulder.
8) Tighten the seatbelt by pulling the diagonal shoulder
belt portion in the direction of the arrows.
Important:
• Lap belt position should be as far forward and as low as possible over child’s
pelvis and contacting upper thighs.
• Diagonal seat belt portion should route inside the red lower belt guide closest to
the buckle and over child’s shoulder. It should NOT be touching the neck.
• NEVER position the shoulder belt loosely or under the child’s arm or behind their back.
• If the diagonal seat belt portion does not correctly t the child, then the seat MUST
only be used with the seatback portion attached and properly adjusted to t the child.
WARNING:
