REAR-FACING
46
ANTI-REBOUND PANEL (ARP)
Diono RECOMENDS using the anti rebound panel
(ARP) with rear-facing installs.
1. Place the ARP into the slots on
the front of the car seat until
hearing an audible "click". Pull bars
outwards to conrm it is locked.
2. Push the buttons on the outside
hinge of the ARP and rotate the
board up until hearing an audible
"click". Pull on ARP to conrm it is
locked into position.
IMPORTANT: DO NOT use the
ARP in any other conguration
than noted for rear-facing
installations.
To remove, press the release
buttons on the outside of the
seat and pull the ARP out.
NOTE: You may need to release
one side at a time.
