5. MAINTENANCE
Cleaning operations
Before cleaning the machine turn the main switch off and unplug the power cord.
Use a damp cloth (not abrasive) for cleaning the base and the outer case. Never use
alcohol or solvents on the written or painted parts.
Maintenance operations
Specialized personnel authorized by the manufacturer must do maintenance.
Do not perform makeshift or ad-hoc repairs, and never use non-original spare parts.
ALWAYS UNPLUG THE ELECTRICITY when carrying out maintenance checks or
operations.
Cleaning operation and replacing the discs.
• UNPLUG THE GRINDER.
• Remove the plastic hopper ( item nr. 230501 )
• Dismantle the aluminum cover ( item nr. 230111 )
• Take apart the upper grinder disc from the aluminum cover ( item nr. 230110 )
• Take apart the lower grinder disc from the bottom side of grinder chamber ( item
nr. 230109 )
• With a brush, clean the grinder discs, clean the rotor (item nr. 230108) blades
from coffee and the discharge tube (item nr. 230007), (eventually it is possible to
use compressed air for those operations).
ADJUSTING THE GRIND
1. Make sure the discs are clean with no coffee or dirt particles on the underside.
2. Install one disc on the rotating disc and the other on the stationary disc,
making sure the screws are tight.
3. Make sure that the top edges of the grinding chamber and the underside of
the stationary disc are perfectly clean.
4. Adjust the grind setting to #9.
5. Align the screw holes of the stationary disc with the grinding chamber and
insert the screws tightly.
6. Replace the cover with the plastic hopper. Now you can plug the grinder in.
