Directechs DB3 - Wiring diagram with T-Harness (THGMD1 Rev.1 & 3)

6
403.GM10 4.16 2011 Chevrolet Cruze
© 2019-03-01 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
16 12
Remote Start
Safety Override
Switch
The Remote Start Safety
Override Switch MUST
be in the ON position.
THGMD1 Rev.1 & 3 (Optional T-Harness)
(-) Parking Lights Output: Black/White
Ignition Connector
(black connector at ignition switch)
(-) RAP Off Output: Green/Black
Hood: White/Black
HS CAN Low: Pin 14
HS CAN High: Pin 6
HS CAN High: Tan/Black
HS CAN Low: Tan
SW CAN: Pin 1
SW CAN: Lt. Green
Ignition Barrel
16
8
9
1
OBDII Diagnostic
(connector side view)
1412
10
42
Hood Pin
Wiring diagram with T-Harness (THGMD1 Rev.1 & 3)
Type 2
NOT USED
Type 1
To
Immobilizer Control Module
(violet connector
under ignition switch)
To
Vehicle
To
Ignition
Away from
Immobilizer Control Module
(vehicle side)
1 2 3 4 5
7
6
121198 10
Headlight Switch
(black 12-pin connector)
(-) Parking Lights: Pin 3, 5 or 7
Refer to the
Vehicle
connections
section for the
corresponding
connector, pin
and wire color
of your vehicle.
(-) Driver Door Trigger
Refer to the Vehicle connections section.
Note: The hood pin is
only required on
vehicles that are not
equipped with a
factory hood pin.
