Directechs DB3 - Wiring diagram with T-Harness (THGM610 D Rev.3)

8
403.GM10 4.16 2011 Chevrolet Cruze
© 2019-03-01 Directed. All rights reserved.
Refer to "Pre-installation and application warnings" for important information, such as the description of each special note referenced in the diagram ( ).
D2D
only
(-) Parking Lights Output: Black/White
Wiring diagram with T-Harness (THGM610D Rev.3)
HS CAN Low: Pin 14
HS CAN High: Pin 6
SW CAN: Pin 1
16
8
9
1
6-pin
connectors
GM 10
GM 10
GM 06
(-) RAP Off Output: Green/Black
OBDII Diagnostic
(connector side view)
1412
10
42
NOT USED
Hood Pin
Note: The hood pin is only required on vehicles
that are not equipped with a factory hood pin.
You can connect
to either a XL202
RFTD OR a SmartStart
module. Refer to the
SmartStart/XL202
Installation Notes for
more information.
HS CAN High: Tan/Black
HS CAN Low: Tan
SW CAN: Lt. Green
Remote Start Safety
Override Switch
T-01
T-02
To
Immobilizer
Control Module
(violet connector
under ignition
switch)
Away from
Immobilizer
Control Module
(vehicle side)
Ignition Barrel
Use connectors
labeled GM10
3-pin
connectors
Ignition Connector
(black connector at
ignition switch)
1 2 3 4 5
7
6
121198 10
Headlight Switch
(black 12-pin connector)
(-) Parking Lights: Pin 3, 5 or 7
Refer to the
Vehicle
connections
section for the
corresponding
connector, pin
and wire color
of your vehicle.
(-) Driver Door Trigger
Refer to the Vehicle connections section.
NOT USED
To
Vehicle
To
Ignition
THGM610D Rev.3 (Optional T-Harness)
