Directed Electronics DB3 User Manual

6 403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
NOT Used
OBDII
OR
Remote Start Safety
Override Switch
OBDII
Diagnostic 16-pin Connector
(vehicle side)
These T-Harness connectors are
NOT interchangeable. They will fit
ONLY the appropriate vehicles.
THCHD3 Rev. 1
(Optional T-Harness)
T-01
6-
pin Black
Connectors
T-02
6-pin White
Connectors
N/C: Violet/Brown
N/C: Violet/White
N/C: Blue/Red
N/C: Orange/Black
N/C: Yellow/Red
Wiring diagram with T-Harness (THCHD3)
