8 403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
Vehicle connections
The connection information listed below is specific to the 2016 Dodge/Ram 1500. Refer to “Pre-installation and application warnings” for a list of important notes.
Data 14-pin blue connector (H1)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H1/1 Light Green No Connection No Connection
H1/2 Violet/Yellow No Connection No Connection
H1/3 Tan/Black HS CAN High data link connector, black 16 pin plug, pin 6 data gray/white (CAN C)
H1/4 TanTan HS CAN Low data link connector, black 16 pin plug, pin 14 data yellow (CAN C)
H1/5 Orange/Green HS CAN2 High data link connector, black 16 pin plug, pin 3 data gray (CAN IHS)
H1/6 Orange/Brown HS CAN2 Low data link connector, black 16 pin plug, pin 11 data white (CAN IHS)
H1/7 Brown Relay 1 N.O. - No Connection No Connection
H1/8 Yellow Relay 1 COM - (+) No Connection No Connection
H1/9 Orange or Orange/Yellow Relay 1 N.C. - No Connection No Connection
H1/10 Orange/Red Relay 2 N.C. - No Connection No Connection
H1/11 Yellow/Red Relay 2 COM - No Connection No Connection
H1/12 Brown/Red Relay 2 N.O. - No Connection No Connection
H1/13 Red (+) 12 Volt BCM under driver dash, black 4 pin plug (B), pin 3 + red (40A)
H1/14 Black (-) Ground
Output 12-pin red connector (H2)
Module Connects To
Conn./Pin Color Description Wire Location (+/-) Wire Color Ref.
H2/1 Black/White No Connection No Connection
H2/2 Green/Black No Connection No Connection
H2/3 Green/White No Connection No Connection
H2/4 Red/Black No Connection No Connection
H2/5 Violet/White No Connection No Connection
H2/6 Gray No Connection No Connection
H2/7 Gray/Black No Connection No Connection
H2/8 Violet/Green No Connection No Connection
H2/9 Violet/Brown No Connection No Connection
H2/10 Yellow/Black No Connection No Connection
H2/11 Orange/Black No Connection No Connection
H2/12 Blue/Red No Connection No Connection
