5 403.CHRYSLER6 2.04 2016 Dodge/Ram 1500
© 2017-01-26 Directed. All rights reserved.
Pre-installation and application warnings
Firmware notes: This section highlights important information for this specific firmware and will assist in
pricing accordingly, as well as bringing awareness to any operational or vehicle limitations.
T-Harness
compatible
THCHD3
Keys required for
programming
1
Keys required for
operation
0
Important! RXT installations are ONLY compatible with vehicles equipped with factory-installed remote starter.
Range Extender Ready (RXT) is used to dramatically increase the factory remote start activation range compared to the
factory transmitter. Refer to the "Quick reference guide" for more information.
SmartStart Compatible: SmartStart is equipped with D2D, which means it can be connected to an interface module
and used in Range Extender Ready (RXT) mode without the use of a remote starter. See "Module programming" for more
information.
The optional Plug & Play THCHD3 T-Harness is sold separately.
The OBDII Diagnostic Connector features will remain the same even when the T-Harness is installed.
Unless specified otherwise, all connectors are displayed from the wire side, with the exception of the OBDII diagnostic
connector.
Refer to "Vehicle connections" following the wiring diagram.
General notes: This section highlights important information for this specific firmware.
[1] HS CAN 2 connections are required for heated seats.
Additional parts required (maximum required):
0 x 1A Diodes
86 85
30
87a
87
0 x Relay
0 x Resistor
0 x Fuse
To Next Page
