User guide P.17
Level 1 (requires pressing the button 1X) Æ Basic features
Level 2 (requires pressing the
button 2X) Æ Customized features
Level 3 (requires pressing the
button 3X) Æ Multi car operation
Example: If the multi-level features was set to option 3, the setup would be as follows:
For “basic features”:
- To access the aux. 2 feature, the user needs to press on the button three (3) times followed
by the button.
- To access cold weather mode, the user needs to press on the button three (3) times followed
by the button.
Diagnostics–ParkingLightFlashTable
Parking lights flashes Description
1
• Doors locked.
• Trunk released.
• Start signal received from the remote.
• Runtime has expired
2 slow
• Shutdown by remote
2 fast
• Doors unlocked
• Valet mode is deactivated
3 slow
• Runtime is extended.
3 fast
• Valet mode activated.
4 fast
• Shutdown by brake
• A remote start was attempted while the brake pedal is engaged.
10 fast
• Shutdown by hood
• A remote start was attempted while the hood is open.
ON Î twice
• Cold weather mode deactivated
ON Î 3 times
• Cold weather mode activated.
Solid ON
• Engine is running under remote start.
Flash for 30 sec.
• Panic mode is triggered.
Flash for 60 sec.
• Alarm is triggered.
ON Î twice Î twice
• A remote start was attempted while the system is in home valet.
