Feature Menus
Default settings are Opt. 1 (in bolder type). New features are bold with grey background.
Menu 1 - Vehicle integration
Menu
Item
Feature Opt. 1 Opt. 2 Opt. 3 Opt.4 Opt. 5+
1 System Locking Mode
Active Locking
Passive Locking Auto Re-
locking*
2
Panic Mode
On
Ign Off only Off
3
Horn Function
Confirmation
Honk (20 ms)
& Panic
Confirmation
Honk (30 ms) &
Panic
Confirmation
Honk (40 ms)
& Panic
Confirmation
Honk (50 ms) &
Panic
Confirmation
Honk Off -
Panic Only
(Pulsed)
4 Ign-controlled locks
No Ign- lock-
ing
Lock & Unlock Lock Only Unlock Only
5
Door Lock Pulses
Single
Double Unlock
Only
Double Lock
Only
Double Lock &
Unlock
6
Door Lock output duration
0.8 sec.
3.5 sec. 0.4 sec.
7
2nd Unlock 2nd unlock on/
Ign-control af-
ter first unlock
2nd unlock on/
Ign-control with
first unlock
8
Comfort Closure
No Comfort
Closure
Comfort Closure
1
Comfort
Closure 2
9 Hood Switch Type
Normally Open
Normally closed
10 Door Switch Type Normally
Open
Normally
Closed
11
Remote Button unlock (Ign off)** On
Off
* The Green H2/6 or the Violet H2/12 wire must be connected to enable this feature.
** Not available with 1-way remote.
1. System Locking mode
1. Active: the transmitter must be used to lock the system
2. Passive Locking: after exiting the vehicle the system will automatically lock the doors
3. Auto re-locking: if the vehicle is not entered after receiving a unlock command, the system will auto-
matically re-lock the doors
2. Panic Mode
1. On: the Panic output can be activated at any time
2. Ign Off Only : the Panic output can be activated only when the ignition is off
3. Off: the Panic output is defeated
3. Horn Duration
1. - Opt 4. 20 - 50 sec: sets the horn output duration with Panic mode at 30 seconds
2. Off: turns the horn output off and with Panic mode at 60 seconds
4. Ign-controlled Locks
1. No Ign-locking: the door lock/unlock outputs will not activate when ignition is turned on/off
2. Lock & Unlock: the door lock & unlock output will activate when ignition is turned on & off
3. Lock Only: the door lock output will activate when ignition is turned on
4. Unlock Only: the door unlock output will activate when ignition is turned off
5. Door Lock Pulses
1. Single: the door lock & unlock outputs will pulse once
2. Double Unlock only: the unlock output only will pulse twice
