C. Using the enclosed coaxial cable, connect one end to the
coaxial connector on your DCCK device labeled “SAT Rcvr”.
D. Connect the other end of the coaxial cable to the coaxial connector
on your Connected Home Adapter labeled “Towards LNB”.
Connect Enclosed Coaxial Cable
to “SAT Rcvr” on DCCK Device
Connect Enclosed Coaxial Cable to “Towards LNB”
on the Connected Home Adapter
directv
®
whole-home dvr service
comPatible with connected home adaPter connection
