Appendix 1: Receivers Front and Back Panels
1. POWER – Turns your DIRECTV
®
Receiver on or off. Your DIRECTV
®
Receiver still tunes and receives messages when powered off. The
power light flashes when you press a key on the remote to let you know it has received the command.
2. REMOTE SENSOR - The infrared sensor picks up commands from the remote control.
3. GUIDE - Displays the on-screen program guide.
4. MENU - Brings up the main menu to access settings and services.
5. ARROWS – Move the on-screen highlight up, down, left or right.
6. SELECT – Selects the item highlighted.
7. DIRECTV ACTIVE
™
CHANNEL – Displays the DIRECTV Active
™
Channel - local weather and more.
8. INFO – Displays channel banner or info for a highlighted program or channel cell.
9. DOOR PANEL – The access card slot, RESET button, receiver ID and model number are located behind the door panel.
