Chapter 3 - Connections for TV and Auxiliary Equipment
67
DIRECTV
®
HD Receiver
DIRECTV
®
SD Receiver
Television
Television
Surround System
VCR/DVD Burner
VCR/DVD Burner
Here is an example of a TV that has an S-Video connector
as the best video input and RCA audio connectors as the best audio
input and a surround sound system with a digital audio optical
connector as the best audio input:
This example also shows using a VCR or DVD burner with RCA
audio and component video connectors.
Example: TV with S-Video Connector
Here is an example of a TV that has an S-Video connector as the
best video input and with RCA connectors as the best audio input:
This example also shows using a VCR or DVD burner with RCA
audio and video connectors.
Example: TV with S-Video Connector
Connections
