ASSEMBLY RECOMMENDATIONS
• Before starting assembly, please read instruc-
tions and follow them during installation process.
• Use the adequate tools for each operation.
ELECTRICITY
• Disconnect ignition key.
• Disconnect battery before starting assembly.
• Make sure electric components are securely
connected, checking their correct tting.
WARNING:
When installing air conditioning equipment on roof,
the upper cabin part must be protected with a cloth
or a protective blanket to avoid possible scratches.
When installing Minicool Compact on roof, take
into account that, normally, cabins equipped with a
hatch have a strong enough structure to hold equip-
ment weight. However, if it is not the case and it is
necessary to carry out a cut in the roof or, although
it has a hatch, the material is not resistant enough (if
roof is made of bre, plastic, etc...), it is the installer
who will have to decide, under his responsibility, if
it is necessary to reinforce the roof to avoid possible
deformations, breaks, water entries, etc., habilitating
the means required to stop it from occurring.
Tools
Tor wrenches set
Allen wrenches set
Open-jawed spanner 10
Open-jawed spanner 13
Open-jawed spanner 14
Scissors
Flexo-meter
WARNINGS:
• The installing personnel must have a sufcient tra-
ining in vehicles air conditioning.
• dirna, s.a. shall not be responsible for break-
downs or damages coming from an inadequate han-
dling or installation of the equipment or from mo-
dications and substitutions carried out without our
express and written authorisation.
• Equipment pre-charged with refrigerating gas,
R-134a, 330 g in each circuit. (Do not handle refri-
gerating gas circuit).
• Please see product warranty procedure included
in Troubleshooting diagnosis.
• Please see equipment User’s Guide for its correct
functioning of the remote control and control panel.
• Once installation is nished, the following docu-
ments must be handed over to the user: User’s Gui-
de, Warranty and Troubleshooting Diagnosis.
DOCUMENTATION INCLUDED WITH
EQUIPMENT:
• Mounting instructions: 220.AA6.0056
• User’s guide: 220.AA6.0057
• Troubleshooting: 220.AA6.0058
• Warranty: 220.AA1.0010
