Dirna Minicool Compact User Manual

dirna, s.a.
18
EN
Id. Qty. Code nº Spare Parts
34 1 0911320055 Plate with serigraphy
35 1 0911320017
Wiring power supply joint
36 1 091132C016 Wiring communication joint
37 1 091132C014 Wiring communication front
38 1 0910870037 Bag of nuts and bolts
39 1 091016C001 Evaporator cooler front
40 1 091016C005 Short canalisation system
40a 1 091016C016 Long canalisation system
41 1 091016C019 Console 615 x 560
41a 1 091016C017 Console 770 x 560
41b 1 091016C018 Console 850 x 560
42 1 091132C010 Electric control
43 1 091132C005 Bag of bolts ,compressor
44 1 091132C017 Joint set external cover
INCLUDED PARTS
Id. Qty. Code nº Spare Parts
1 1 091087C016
Rear grid
2 1 091139C001
Outside cover
3 1 091087C014
Electric fan
4 1 091132C002
Lower cover w/cover
5 1 091132C003
Condenser
6 1 091087C015
Air inlet grid
7 1 091016C028 Tap with cover
8 1 3303270000
10 tting
9 1 091132C004
Compressor set
10 1 091132C006
Coil
11 1 091132C007
right Capillary
12 1 091132C008
left Capillary
13 1 0911320044
Electronic module
14 1 3303260000
10 tting
15 1 091087C006
Pressuriser
16 1 3303250000
10 tting
17 1 091139C003
Fastening support
18 1 091087C004
Drainage tray set
19 1 091087C005
Drainage valve
20 1 091132C009
Base long
20a 1 091143C001
Base Short
21 1 3303240000
10 tting
22 1 091016C024
EPDM joints
23 1 0910520022
Probe
24 1 091016C004
Electronic cover
25 1 0911320015 Wiring modules set
26 1 0910870121
Remote control
27 1 091139C002
Wiring for battery power supply
28 1 091132C013
Camp with Screws
29 1 0910870028
Electro wiring
30 1 091016C002
Circular air vent
31 1 091132C015 Wiring communication
32 1 0910160058
band with connectors
33 1 0911320016
wiring panel power supply
