MIDI Input and Output
While the SMARTClock can generate MIDI clock and program change messages on its own, it can also function as part of a larger MIDI
system thanks to its MIDI input and USB MIDI ports.
To use the SMARTClock with a Disaster Area or other MIDI controller, change the InCH setting in the Setup menu to match the
channel that your master controller sends. If you are connecting to a Disaster Area controller, set InCH = 16. We also recommend you
disable the MIDI clock sending on your master controller, if possible. Disaster Area controllers should set CLK = OFF or TAP.
If InCH is set to OFF, the SMARTClock MIDI thru will be disabled.
The SMARTClock responds to the following MIDI messages:
Program Change 0-127: Change preset 0-127
Continuous Controller 93: Tap Tempo
MIDI Beat Clock: Disables internal clock
MIDI Stop: Disables internal clock
MIDI Continue: Re-send tap tempo pulses
External MIDI Clock
Note that if the SMARTClock receives MIDI clock from an external source, its internal clock will be disabled.
The display will show E in addition to the BPM to indicate that it is receiving clock. If the external clock signal is removed or lost, the
SMARTClock will restart its internal clock using the last BPM received.
Sending the SMARTClock a MIDI Continue message will cause the controller to re-send the tap tempo pulses.
MIDI Interface Mode
The SMARTClock can function as a USB MIDI interface, allowing you to access external MIDI gear from your computer. This mode will
disable all of the SMARTClock’s internal functions, dedicated its full processing power to interface duty.
To engage interface mode, power on the SMARTClock while connected to a USB host such as a PC or Mac. While the display is
scrolling, hold the footswitch down. The display will show “INT” and the SMARTClock will be in interface mode.
To exit interface mode, power cycle the SMARTClock.
