8500 Tracking System Operator’s Manual Controls - 27
8500D
CMW
Quick Functions
Contrast Adjustment
To adjust contrast, press and hold left button (1) and press button 2 to darken/increase contrast or button 3
to lighten/lessen contrast.
Backlight Toggle
To turn backlight on and off, press and hold left button (1) and press power (4) button. Don’t press power
button for more than 2 seconds to avoid turning unit off.
3. Delete button Press to delete previous pipe
data.
4. Power/Menu button To turn on, press once.
To turn off, press for 2
seconds.
Press button less than 2 seconds to
access menu.
Item Description Notes
si1017a-d.eps
