Tracking Concepts - 50 8500 Tracking System Operator’s Manual
Ghost Signal Responses
CMW
Ghost Signal Responses
The locate arrows will change direction and point
away from the beacon (as shown) as the tracker
reaches a ghost signal. The distance from the
beacon plane to the ghost signals increases with
increasing depth.
To avoid locating ghost signals, rotate tracker
parallel to bore path (shown below) and watch the
solid circle in the field balance bar to get near the
beacon plane.
