FM13V/FM13X Operator’s Manual Specifications - 55
Specifications
Dimensions with 1000-gal (3785-L) tank U.S. Metric
L Length (as shown; variable with layout flexibility) 80 in 4.57 m
W Width (as shown; variable with layout flexibility) 42 in 1.07 m
H Height, without fill pipe 72 in 1.83 m
Height, with fill pipe 80 in 2.03 m
Weight, mixing unit 450 lb 205 kg
Weight, 950 gal (3596 L) tank with hoses 1000 lb 454 kg
System weight with 950 gal (3596 L) of fluid in tank 8,933 lb 4052 kg
Dimensions with 500-gal (1892-L) tank U.S. Metric
L Length (as shown; variable with layout flexibility) 150 in 3.81 m
W Width (as shown; variable with layout flexibility) 31 in 787 mm
H Height, without fill pipe 68 in 1.73 m
Height, with fill pipe 75 in 1.91 m
Weight, mixing unit 450 lb 205 kg
Weight, 500 gal (1890 L) tank with hoses 550 lb 250 kg
System weight with 500 gal (1890 L) of fluid in tank 5160 lb 2341 kg
