Controls - 20
FM25/FM25X Operator
’s Manual
Power Unit
Power Unit
1.
Ignition
2.
Fuel gauge
3.
Hourmeter
4.
Engine oil pressure
indicator
5.
Coolant temperat
ure indicator
6.
Glow plug wait indicator
7.
Glow p
lug button
8.
Auxiliary outlet
9.
Throttle
10.
Pump 2 control
1
1.
Pump 1 control
Item
Description
Notes
1.
Ignition
T
o star
t engine, insert key a
nd
turn clockwise.
T
o stop engine, turn key
counterclockwise.
20
