Specifications - 64 FM25/FM25X Operator’s Manual
Dimensions with two 500-gal (1892-L) tanks U.S. Metric
L Length (as shown; variable with layout flexibility) 175 in 4.45 m
W Width (as shown; variable with layout flexibility) 92 in 2.34 m
H Height, without fill pipe 68 in 1.73 m
Height, with fill pipe 75 in 1.91 m
Weight, dry 2350 lb 1070 kg
System weight, with fluid (500 gal/1890 L per tank) 10, 650 lb 4830 kg
Performance U.S. Metric
Centrifugal pump suction port diameter 3 in 76 mm
Centrifugal pump discharge port diameter 3 in 76 mm
Maximum fluid pressure 50 psi 3.4 bar
Maximum pump discharge rate (each pump) 300 gpm 1100 L/min
Flow rate to drilling unit (42 viscosity fluid @ 30 psi/2.1 bar through
3”/76mm X 50’/15 m hose)
0-200 gpm 0-750 L/min
Drilling fluid tank capacity (nominal, each tank) 500/950 gal 1890/3596 L
Solids addition rate with metering plate 30 lb/min 14 kg/min
Solids addition rate without metering plate 75 lb/min 34 kg/min
Dry mixing hopper capacity
1 ft
3
28 L
Typical tank mixing time 7-10 min
