Specifications - 192
RT80Q Operator’s Manual
H810 Trencher
Operation
U.S.
Metric
Headshaft speeds at 2600 engine rpm
Ratio low
170 rpm
170 rpm
Ratio standard
208 rpm
208 rpm
Ratio high (not recommended)
280 rpm
280 rpm
Digging chain speeds at 2600 engine rpm
Ratio low
485 ft/min
148 m/min
Ratio standard
592 ft/min
180 m/min
Ratio high (not recommended)
798 ft/min
243 m/min
192
194
