3
DITEC S.P.A - IP1580 30/06/99 - CS61/CS61E
Fig. 1
Impianto tipo
Standard installation
Installation type
Standard Montage
Instalaciòn tipo
I
UK
F
D
E
TX - 4x0.5 mm²
RX-4x0.5 mm²
4x0.5 mm²
1
3
2
5
3x1.5 mm²
2x1.5 mm²
4
8
5
6
6
7
