CHAPTER 3
INSTALLATION
3-6
Displays of series DT-203NN, DT-105NN and DT-110NN
Then we must connect it to the display tightening the screws with a screwdriver for let it well
secured, then with the help of a tool we have to tight the cable gland of the connector to acquire
finally the protection wished.
Improper installation cancels the protection IP65 and the warranty.
