Displays for series DT-203NN, DT-105NN and DT-110NN
4.2.3 Parameter description.
4.2.3.1 Parameter: LANGUAGE or LA.
Allows set the language. There are four languages available: Catalan, Spanish,
French and English.
4.2.3.2 Parameter: Configuration.
Set the operating mode for the messages. There are 2 options:
1. Code selection: In this mode, once the messages on the display have been
edited and stored, they are activated by sending only the message number.
2. Direct message control: By selecting this type of control, the text messages
have to be sent as well as control commands that performs special functions,
such as flashing a message section, controlling the brightness, inserting the
date and time, line feed in the multiline displays, etc.
In sections 5.2.1 and 5.2.2 these operating modes are fully explained.
The internal memory of the equipment comes pre-loaded with factory default messages.
If a new list is generated, it must contain at least message 0, wich is displayed when the
display is powered.
4.2.3.3 Parameter: Protocol.
The available protocols are: TDL, PROFINET.
• TDL: Protocol by serial line RS232, which is used in conjunction with
the TDLWin program for store messages in the equipment memory and
displays them in debug mode.
• PROFINET: Industrial standard based on Ethernet, wich is configured
using engineering tools such as TIA Portal by Siemens, or similar from
other PLC manufacturers.
4.2.3.4 Parameter: Date.
Set the display date (can also be configured by Profinet)
4.2.3.5 Parameter: Time
Set the display time. The new time value will be initialized when you quit parameter
configuration. The time can also be set by Profinet.
4.2.3.6 Parameter: POS. CONNECTORS or CON
Select the power and Profinet connectors’ position. Depending on the installation, it may be
more convenient for the connectors to come out at the top or at the bottom of the display. This
parameter reverses the text if the display is installed in reverse position.
