Ditel DT-203 Series User Manual

CHAPTER 2 GENERAL CHARACTERISTICS 2-1
Displays of series DT-203NN, DT-105NN and DT-110NN
2 GENERAL CHARACTERISTICS.
2.1 Electrical characteristics of the displays
2.1.1 Electrical characteristics of the DT-203 displays.
Supply Voltage........................................... 100 to 240 VAC 50/60Hz or 24VDC option.
Consumption ............................................. See section 2.2.
Display ....................................................... 7x5 Dot matrix of 30mm high.
..................................................................... Red Led colour. Visibility 15 meters.
Parameter memory .................................... Eeprom.
Watch calendar .......................................... Second / Minute / Hour / Day / Month / Year.
Environmental Conditions ........................ Operation Temperature: -20 to 60ºC.
..................................................................... Storage temperature: -30ºC to 70ºC.
..................................................................... Humidity: 20-90% without condensation.
..................................................................... Maximum environmental illumination: 1000 lux.
..................................................................... Sealing: IP41, IP54 and IP65.
2.1.2 Electrical characteristics of the DT-105 displays.
Supply Voltage........................................... 100 to 240 VAC 50/60Hz or 24VDC option.
Consumption ............................................. See section 2.2.
Display ....................................................... 7x5 Dot matrix of 50mm high.
..................................................................... Red Led colour. Visibility 25 meters.
Parameter memory .................................... Eeprom.
Watch calendar .......................................... Second / Minute / Hour / Day / Month / Year.
Environmental Conditions ........................ Operation Temperature: -20 to 60ºC.
..................................................................... Storage temperature: -30ºC to 70ºC.
..................................................................... Humidity: 20-90% without condensation.
..................................................................... Maximum environmental illumination: 1000 lux.
..................................................................... Sealing: IP41, IP54 and IP65.
2.1.3 Electrical characteristics of the DT-110 displays.
Supply Voltage........................................... 100 to 240 VAC 50/60Hz or 24VDC option.
Consumption ............................................. See section 2.2.
Display ....................................................... 7x5 Dot matrix of 100mm high.
..................................................................... Red Led colour. Visibility 50 meters.
Parameter memory .................................... Eeprom.
Watch calendar .......................................... Second / Minute / Hour / Day / Month / Year.
Environmental Conditions ........................ Operation Temperature: -20 to 60ºC.
..................................................................... Storage temperature: -30ºC to 70ºC.
..................................................................... Humidity: 20-90% without condensation.
..................................................................... Maximum environmental illumination: 1000 lux.
..................................................................... Sealing: IP41, IP54 and IP65.

Ditel DT-203 Series Specifications

General

Brand	Ditel
Model	DT-203 Series
Category	Monitor
Language	English
