Displays for series DT-203NN, DT-105NN and DT-110NN
4 OPERATION
4.1 Initial Start Up.
The DT-NN display is controlled by Profinet comunication.
Every time the display is connected to the power supply, three blocks of illuminated
LEDs are displayed moving throught the display. This allows to visualize the status of the LEDs.
Then, the display reads the message memory and initialises the message table.
During this time (It can take several seconds if there are many messages) the word
“INICI” is shown.
When the initialisation process is finished, the display will be ready to receive messages
from the network. While the display does not receive the first message, it shows the messages
of the internal memory, depending on the selected protocol:
Protocol TDL: Display all memory messages. Presentation mode.
Protocol PROFINET: Display message 0.
4.2 Programming parameters.
Before using the display, the configuration parameters must be set as required.
The parameters configuration is done through a menu that is selected by two buttons
placed at the bottom part of the display. The field that can be modified is displayed flashing.
4.2.1 Enter to modify parameters.
In order to enter the sequence to modify the parameters, the Advance key “” must be
pressed and held for three seconds. After this, the first parameter will be displayed, with the
parameter name flashing.
There are then two options:
1- Modify the parameter value.
• Press the Advance key “” and change the selected parameter.
• To return to the parameter name, press again “” key.
• To surf over the parameter options, press “
+” key. When you arrive to the end
of the options list, press again “
+” key to go back to the first option.
2- Select another parameter.
Press “” key to flash the “parameter name” (if the “parameter option” is flashing) and
use “
+” key to select other parameters.
4.2.2 Quit parameter configuration
Select “EXIT” parameter and press “” to quit.
