Lock ring
■
How to remove
While pulling the battery lock lever (black) on the bottom of the
Light Module in the direction of , turn the Battery Module’s
lock ring in the direction of as far as it will go and
pull it out. Be sure to position the modules as illustrated when
detaching them to prevent water from getting inside the Battery
Module.
Battery lock lever (Black)
52
