ASURITY
TM
CONDENSATE MANAGEMENT PAGE
10
OPERATION (CONTINUED)
2. TESTING OVERFLOW SWITCH (IF CONNECTED)
Remove the top of the pump from the tank. Move the oat up by
hand until the pump motor turns on and the fan is audible. If overow
safety switch is wired correctly, the appliance will shut down, and the
condensate pump will pump out water.
MAINTENANCE AND DISASSEMBLY
ALWAYS disconnect power before performing maintenance. Pump and
deck may be removed from tank by pushing tabs located on tank sides
away from deck while lifting on pump cover.
Periodically inspect the
condensate pump tank
to ensure it is free of
accumulated dirt or sludge.
DO NOT use solvent
cleaners. Clean tank with
soap and warm water only.
Check valve may be removed
for cleaning or replacement
by unscrewing with a 5/8”
wrench.
Clean inlet and outlet piping.
Reassemble system and
check for correct operation.
A
2
1
1
2
