XW60K
EN
STANDARD VALUES
Defrost Defrost Defrost
BY AIR BY HOT GAS BY HEATERS
Label Description Range
Default
Level TA
TN TB TN TB
SEt Set point LS÷US -5
-
10 0 -22 0 -22
Hy Differential 0,1÷25,5 °C / 1÷45°F 2 Pr1 2 2 2 2 2
LS Minimum set point
-50,0°C÷SET / -58°F÷SET
-50 Pr2 10 -5 -25 -5 -25
US Maximum set point
SET ÷ 110°C / SET ÷ 230°F
110 Pr2 15 5 -18 5 -18
ot Thermostat probe calibration -12
÷
12°C / -120
÷
120°F 0 Pr1 0 0 0 0 0
P2P Evaporator probe presence n; Y Y Pr1 n y y y y
oE Evaporator probe calibration -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
P3P Third probe presence (1st cond. probe) n; Y n Pr2 n n n n n
o3 Third probe calibration -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
P4P Fourth probe presence (2nd cond. probe) n; Y n Pr2 n n n n n
o4 Fourth probe calibration -12
÷
12°C / -120
÷
120°F 0 Pr2 0 0 0 0 0
odS Outputs activation delay at start up 0÷255 min. 0 Pr2 0 0 0 0 0
AC Anti-short cycle delay 0÷30 min. 1 Pr1 2 2 2 2 2
AC1 Second compressor delay 0÷255s 5 Pr2 0 0 0 0 0
rtr P1-P2 percentage for regulation 0 ÷ 100 (100=P1, 0=P2) 100 Pr2 100 100 100 100 100
CCt Compressor ON time during fast freezing 0 ÷ 23h 50 min. 0 Pr2 0 0 0 0 0
CCS Set point for continuous cycle (-55.0÷150,0°C) -5 Pr2 -5 -5 -5 -5 -5
Con Compressor ON time with faulty probe 0÷255 min. 15 Pr2 0 0 0 0 0
CoF Compressor OFF time with faulty probe 0÷255 min. 30 Pr2 0 0 0 0 0
CF Temperature measurement unit °C ÷ °F °C Pr2 c c c c c
rES Resolution (integer/decimal point) in ÷ de dE Pr1 in in in in in
rEd Remote display P1 ÷ 1r2 P1 Pr2 P1 P1 P1 P1 P1
dLy Display temperature delay 0 ÷ 20.0 min (10 sec.) 0 Pr2 0 0 0 0 0
dtr P1-P2 percentage for disply 1 ÷ 99 50 Pr2 50 50 50 50 50
tdF Defrost type EL, in EL Pr1 EL in in EL EL
dFP Probe selection for defrost termination nP; P1; P2; P3; P4 P2 Pr2 P2 P2 P2 P2 P2
dtE Defrost termination temperature -50,0÷110°C / -58÷230°F 8 Pr1 20 20 20 30 30
idF Interval between defrost cycles 1÷120h 6 Pr1 3 3 3 3 3
MdF (Maximum) length for 1° defrost 0÷255 min. 30 Pr1 20 20 20 30 30
dSd Start defrost delay 0÷99 min. 0 Pr2 0 0 0 0 0
dFd Displaying during defrost rt, it, SEt, dEF, dEG it Pr2 rt rt rt rt rt
dAd MAX display delay after defrost 0÷255 min. 30 Pr2 0 0 0 0 0
Fdt Draining time 0÷60 min. 0 Pr2 0 2 2 2 2
dPo First defrost after start up n ÷ y n Pr2 n n n n n
dAF Defrost delay after fast freezing 0 ÷ 23h 50 min. 0 Pr2 0 0 0 0 0
FnC Fans operating mode C-n, C-y, O-n, O-y o-n Pr1 o-y o-n o-n o-n o-n
Fnd Fans delay after defrost 0÷255 min. 10 Pr1 3 3 3 3 3
FCt
Differential of temperature for forced activation of fans
0÷50°C 10 Pr2 0 0 0 0 0
FSt Fans stop temperature
-50,0÷110°C / -58÷230°F
2 Pr1 40 40 40 40 40
Fon Fan on time with compressor off 0÷15 (min.) 0 Pr2 0 0 0 0 0
FoF Fan off time with compressor off 0÷15 (min.) 0 Pr2 0 0 0 0 0
FAP Probe selection for fan management nP; P1; P2; P3; P4 P2 Pr2 nP P2 P2 P2 P2
ACH Kind of action for auxiliary relay CL; Ht cL Pr2 CL CL CL CL CL
SAA Set Point for auxiliary relay -50,0÷110°C / -58÷230°F 0 Pr2 0 0 0 0 0
SHy Differential for auxiliary relay 0,1÷25,5 °C / 1÷45°F 2 Pr2 2 2 2 2 2
ArP Probe selection for auxiliary relay nP / P1 / P2 / P3 nP Pr2 nP nP nP nP nP
Sdd Aux.output working during defrost n, y n Pr2 n n n n n
ALP Probe setting for temperature alarm P1÷P4 P1 Pr2 P1 P1 P1 P1 P1
ALC Temperature alarms configuration rE÷Ab rE Pr2 re re RE re RE
ALU MAXIMUM temperature alarm -50,0÷110°C / -58÷230°F 10 Pr1 5 5 5 5 5
ALL minimum temperature alarm -50,0÷110°C / -58÷230°F 10 Pr1 5 5 5 5 5
AFH Temperature alarm and fan differential 0,1÷25,5 °C / 1÷45°F 2 Pr2 2 2 2 2 2
ALd Temperature alarm delay 0÷255 min. 15 Pr2 15 15 15 15 15
dAo Delay of temperature alarm at start up 0 ÷ 23h 50 min. 1,3 Pr2 3 3 4 3 4
AP2 Probe for temperat. alarm of condenser nP; P1; P2; P3; P4 P4 Pr2 nP nP nP nP nP
AL2 Condenser for low temperat. alarm
(-55 ÷ 150°C) (-67÷ 302°F) -40 Pr2 -40 -40 -40 -40 -40
AU2 Condenser for high temperat. alarm
(-55 ÷ 150°C) (-67÷ 302°F) 110 Pr2 110 110 110 110 110
AH2 Differ. for condenser temp. alar. recovery
[0,1°C ÷ 25,5°C] [1°F ÷ 45°F]
5 Pr2 5 5 5 5 5
Ad2 Condenser temperature alarm delay 0 ÷ 254 (min.), 255=nU 15 Pr2 15 15 15 15 15
dA2 Delay of cond. temper. alarm at start up 0.0 ÷ 23h 50’ 1,3 Pr2 1,3 1,3 1,3 1,3 1,3
AC2 Compr. off for condenser high temperature alarm n(0) - y(1) n Pr2 n n n n n
bLL Compr. off for condenser low temperature alarm n(0) - Y(1) n Pr2 n n n n n
tbA Alarm relay disabling n=no; y=si y Pr2 y y y y y
oA3 Fourth relay configuration ALr; dEF; Lig; AUS; Lig Pr2 Lig Lig. Lig. Lig. Lig.
onF; Fan; db; dF2
AOP Alarm relay polarity oP; cL cL Pr2 cL cL cL cL cL
i1P Digital input polarity oP; CL cL Pr1 Op Op Op Op Op
i1F Digital input configuration EAL, bAL, PAL, dor; dor Pr1 dor dor dor dor dor
dEF; Htr, AUS
did Digital input alarm delay 0÷255 min. 15 Pr1 60 60 60 60 60
nPS Number of activation of pressure switch 0 ÷15 15 Pr2 10 10 10 10 10
OdC Compress and fan status when open door no; Fan; CPr; F_C F-c Pr2 f-c f-c f-c f-c f-c
rrd Regulation restart with door open alarm n – Y y Pr2 n n n n n
HES Differential for Energy Saving -30°C÷30°C; -54°F÷54°F 0 Pr2 0 0 0 0 0
PbC Kind of probe Ptc; ntc ntc Pr2 ntc ntc ntc ntc ntc
Adr Serrial address 1÷247 1 Pr1 1 1 1 1 1
OnF on/off key enabling nu, oFF; ES oFF Pr2 oFF oFF oFF oFF oFF
dP1 Room probe display
-
-
Pr1
-
-
-
-
-
dP2 Evaporator probe display
-
-
Pr1
-
-
-
-
-
dP3 Third probe display
-
-
Pr1
-
-
-
-
-
dP4 Fourth probe display
-
-
Pr1
-
-
-
-
-
rSE Current set point
-
-
Pr1
-
-
-
-
-
rEL Software release
-
1,1 Pr2 1,1 1,1 1,1 1,1 1,1
Ptb Map code
-
-
Pr2
-
-
-
-
-
