dIXEL
Installing and Operating Instructions
1592020570
1592020570 XR70CX RTC GB r1.0 28.05.2008.doc XR70CX 5/5
Lab
Name Range °C/°F Level
ALU
MAXIMUM temperature alarm
Set÷110.0°C; Set÷230°F
110 Pr1
ALL
Minimum temperature alarm
-50.0°C÷Set/ -58°F÷Set
-50.0 Pr1
AFH
Differential for temperat. alarm recovery (0,1°C÷25,5°C) (1°F÷45°F) 1 Pr2
ALd
Temperature alarm delay
0 ÷ 255 min
15 Pr2
dAO
Delay of temperature alarm at start up
0 ÷ 23h e 50’
1.3 Pr2
AP2
Probe for temperat. alarm of condenser nP; P1; P2; P3; P4 P4 Pr2
AL2
Condenser for low temperat. alarm (-55 ÷ 150°C) (-67÷ 302°F) -40 Pr2
AU2
Condenser for high temperat. alarm (-55 ÷ 150°C) (-67÷ 302°F) 110 Pr2
AH2
Differ. for condenser temp. alar. recovery [0,1°C ÷ 25,5°C] [1°F ÷ 45°F] 5 Pr2
Ad2
Condenser temperature alarm delay 0 ÷ 254 (min.) , 255=nU 15 Pr2
dA2
Delay of cond. temper. alarm at start up 0.0 ÷ 23h 50’ 1,3 Pr2
bLL
Compr. off for condenser low
temperature alarm n(0) - Y(1)
n Pr2
AC2
Compr. off for condenser high
temperature alarm n(0) - Y(1)
n Pr2
tbA
Alarm relay disabling n=no; y=yes y Pr2
oA3
Fourth relay configuration
Lr = alarm; dEF = do not select
it; Lig =Light; AUS =AUX;
onF=always on; Fan= do not
select it; db = do not select it;
dF2 = do not select it
ALr Pr2
AoP
Alarm relay polarity (oA3=ALr) oP; cL cL Pr2
i1P
Digital input polarity oP=opening;CL=closing cL Pr1
i1F
Digital input configuration
EAL, bAL, PAL, dor; dEF; Htr, AUS
dor Pr1
did
Digital input alarm delay 0÷255min 15 Pr1
Nps
Number of activation of pressure switch
0 ÷15
15 Pr2
odc
Compress and fan status when open
door
no; Fan; CPr; F_C
F-c Pr2
rrd
Regulation restart with door open alarm n – Y y Pr2
HES
Differential for Energy Saving (-30°C÷30°C) (-54°F÷54°F) 0 Pr2
Hur
Current hour 0 ÷ 23 - rtc
Min
Current minute 0 ÷ 59 - rtc
dAY
Current day Sun ÷ SAt - rtc
Hd1
First weekly holiday Sun÷ SAt – nu nu rtc
Hd2
Second weekly holiday Sun÷ SAt – nu nu rtc
ILE
Energy Saving cycle start during
workdays
0 ÷ 23h 50 min. 0 rtc
dLE
Energy Saving cycle length during
workdays
0 ÷ 24h 00 min. 0 rtc
ISE
Energy Saving cycle start on holidays 0 ÷ 23h 50 min. 0 rtc
dSE
Energy Saving cycle length on holidays 0 ÷ 24h 00 min. 0 rtc
Ld1
1
st
workdays defrost start 0 ÷ 23h 50 min. - nu 6.0 rtc
Ld2
2
nd
workdays defrost start 0 ÷ 23h 50 min. - nu 13.0 rtc
Ld3
3
rd
workdays defrost start 0 ÷ 23h 50 min. - nu 21.0 rtc
Ld4
4
th
workdays defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
Ld5
5
th
workdays defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
Ld6
6
th
workdays defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
Sd1
1
st
holiday defrost start 0 ÷ 23h 50 min. - nu 6.0 rtc
Sd2
2
nd
holiday defrost start 0 ÷ 23h 50 min. - nu 13.0 rtc
Sd3
3
rd
holiday defrost start 0 ÷ 23h 50 min. - nu 21.0 rtc
Sd4
4
th
holiday defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
Sd5
5
th
holiday defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
Sd6
6
th
holiday defrost start 0 ÷ 23h 50 min. - nu 0.0 rtc
PbC
Kind of probe
Ptc; ntc
1 Pr2
Adr
Serrial address
1÷247
1 Pr2
onF
on/off key enabling nu, oFF; ES ntc Pr1
dP1
Room probe display
--
nu Pr2
dP2
Evaporator probe display
--
-- Pr1
dP3
Third probe display
--
-- Pr1
dP4
Fourth probe display
--
-- Pr1
rSE
Valore set operativo actual set -- Pr2
rEL
Software release -- -- Pr2
Ptb
Map code -- -- Pr2
2
Only for models XR70CX–xx2xx, XR70CX–xx3xx; XR70CX–xx6xx; XR70CX–xx7xx
Dixell S.p.A. Z.I. Via dell’Industria, 27
32010 Pieve d’Alpago (BL) ITALY
tel. +39 - 0437 - 98 33 - fax +39 - 0437 - 98 93 13
E-mail: dixell@dixell.com - http://www.dixell.com
