dixell XR70CX User Manual

1592020070 XR70CX GB m&M r1.3 08.05.2012.doc XR70CX 5/5
Label
Name Range Value
Level
tdF Defrost type EL; in EL Pr1
dFP
Probe selection for defrost termination nP; P1; P2; P3; P4 P2 Pr2
dtE Defrost termination temperature
[-55 to 50.0°C]
[-67 to 122°F]
8 Pr1
idF Interval between defrost cycles 0 to 120 hours 6 Pr1
MdF
(Maximum) length for defrost 0 to 255 min 30 Pr1
dSd
Start defrost delay 0 to 255 min 0 Pr2
dFd
Displaying during defrost rt; it; SEt; dEF it Pr2
dAd
MAX display delay after defrost 0 to 255 min 30 Pr2
Fdt Draining time 0 to 255 min 0 Pr2
dPo
First defrost after start-up n; Y n Pr2
dAF
Defrost delay after fast freezing 0.0 to 24h00min, res. 10 min 0.0 Pr2
FnC
Fan operating mode C-n; o-n; C-Y; o-Y o-n Pr1
Fnd
Fan delay after defrost 0 to 255 min 10 Pr1
FCt
Differential of temperature for forced
activation of fans
[0 to 50°C]
[0 to 90°F]
10 Pr2
FSt Fan stop temperature
[-55 to 50.0°C]
[-67 to 122°F]
2 Pr1
Fon
Fan on time with compressor off 0 to 15 min 0 Pr2
FoF
Fan off time with compressor off 0 to 15 min 0 Pr2
FAP
Probe selection for fan management nP; P1; P2; P3; P4 P2 Pr2
ALC
Temperat. alarms configuration rE; Ab Ab Pr2
ALU
MAXIMUM temperature alarm
Rel: [0.0 to 50.0°C] [0 to 90°F]
AbS: [ALL to 150°C] [ALL to 302°F]
110.0
Pr1
ALL
Minimum temperature alarm
Rel: [0.0 to 50.0°C] [0 to 90°F]
AbS: [-100°C to ALU] [-148°F to
ALU]
-50.0 Pr1
AFH
Differential for temperat. alarm recovery
[0.1 to 25.5°C]
[1 to 45°F]
1.0 Pr2
ALd
Temperature alarm delay 0 to 255 min 15 Pr2
dAo
Delay of temperature alarm at start up 0.0 to 24h00min, res. 10 min 1.3 Pr2
AP2
Probe for temperat. alarm of condenser nP; P1; P2; P3; P4 P4 Pr2
AL2
Condenser for low temperat. alarm
[-100 to 150°C]
[-148 to 302°F]
-40 Pr2
AU2
Condenser for high temperat. alarm
[-100 to 150°C]
[-148 to 302°F]
110 Pr2
AH2
Differ. for condenser temp. alar.
recovery
[0.1 to 25.5°C]
[1 to 45°F]
5 Pr2
Ad2
Condenser temperature alarm delay 0 to 254 min, 255(nu) 15 Pr2
dA2
Delay of cond. temper. alarm at start up
0.0 to 24h00min, res. 10 min 1.3 Pr2
bLL
Compr. off for condenser low
temperature alarm
n; Y n Pr2
AC2
Compr. off for condenser high
temperature alarm
n; Y n Pr2
tbA Alarm relay disabling n; Y Y Pr2
oA3
Fourth relay configuration
ALr = alarm; dEF = do not select it;
LiG =Light; AUS =AUX; onF=always
on; FA
n= do not select it; db = neutral
zone; CP2 = second compressor;
dF2 = do not select it
ALr Pr2
AoP
Alarm relay polarity (oA3=ALr) oP; CL CL Pr2
i1P Digital input polarity (18-19) oP; CL CL Pr1
i1F Digital input configuration (18-19)
EAL; bAL; PAL; dor; dEF; ES; AUS;
Htr; FAn; HdF; onF
dor Pr1
did Digital input alarm delay (18-20) 0 to 255 min 15 Pr1
nPS
Number of activation of pressure switch 0 to 15 15 Pr2
odC
Compress and fan status when open
door
no; FAn; CPr; F-C F-C Pr2
rrd Regulation restart with door open alarm n; Y Y Pr2
HES
Differential for Energy Saving
[-30 to 30°C]
[-54 to 54°F]
0 Pr2
Adr Serial address 0 to 247 1 Pr2
PbC
Kind of probe PtC; ntC ntC Pr2
onF
on/off key enabling nu; oFF; ES nu Pr2
dP1
Room probe display probe value - Pr1
dP2
Evaporator probe display probe value - Pr1
dP3
Third probe display probe value - Pr1
dP4
Fourth probe display probe value - Pr1
rSE Real set actual set - Pr2
rEL Software release read only - Pr2
Ptb Map code read only - Pr2

dixell XR70CX Specifications

General

Model	XR70CX
Category	Controller
Power Consumption	3 VA max
Resolution	0.1°C
Dimensions	32x74x60 mm
Mounting	Panel mounting
Operating Temperature	0°C to 60°C
Storage Temperature	-30°C to 85°C
Inputs	NTC or PTC probes
Digital Inputs	1
Outputs	Relay
Display	3 digits, red LED
Protection Degree	IP20
Relative Humidity	20% to 85% (non-condensing)
