ITEM PART
NO. DESCRIPTION NO.
31. Hex Bolt
1/2
"-13 x
3/4
"……………….. B-115
32. Hex Bolt
5/8
"-11 x 1"………………… B-120
33. "V"-Idler Pulley………………………
30234
34. Bronze Bushing………………………. 30206
35. Flat Idler Pulley……………………….
30224
36.
3/8
" Flat Washer……………………… W-104
37. Ser. Flange Hex Nut
3/8
"-16………… N-108
38. Bronze Bushing………………………. 20276
39. Shoulder Bolt
1/2
"-13 x 1-
3/4
"………. B-118-G
40. Clevis Pin
3/8
" x 1-
1/4
"………………. P-102
41. Stabilizer Bar…………………………. 30214-86
42. Hex Bolt
1/2
"-13 x 1-
1/4
"……………
B-117
43.
1/2
" Flat Washer……………………… W-109
44. Long Tensioning Spring………………10222
45. Tower Assembly Weldment…………
67131
Deck Spindle Belt (A-89)……………
63203
ITEM PART
NO. DESCRIPTION NO.
1. Clevis Pin
3/8
"x2-
1/4
" Long…………
P-103
2. Clevis Pin
3/8
"x1-
1/2
" Long…………
P-102
3. Hairpin Cotter…………………………
20224
4. Rod End Stud………………………… S-114 (#50)
Nut…………………………………. N-157
Deck Lift Chain #50………………
68217
Master Link #50…………………
10232
5. Clevis Pin
5/16
"x1"……………………
P-101
6. L.H. Scissor Link Arm………………
30232
7. 42" Blow-Out Baffle…………………
50315-42
8. R.H. Scissor Link Arm………………
30231
9. Clevis Pin
3/8
"x1-
1/2
" Long…………
P-102
10. Clevis Pin
3/8
"x2-
1/4
" Long…………
P-103
11. 42" Mower Deck Complete…………
30200-42
42" Mower Deck Shell……………67350
12. Mulch Plate…………………………… 50122-42
13. Cam Weldment……………………….
30210
14. Engaging Shaft……………………….. 30211
15. Hairpin Cotter…………………………
30213
16. Engaging Handle……………………
30212
17. Handle Grip……………………………
67258-R
18. Engaging Rod…………………………
68209
19. Return Spring…………………………. 20217-25
20. L Bracket……………………………… 30209-B
21. Engaging Spring……………………… 30207-S
22. Engaging Rod Assembly……………
30209-1
23. Hex Nut
1/4
"-20 ………………………
N-102
24. Hex Bolt
1/4
"-20 x
3/4
"………………
B-102
25. Belt Tensioning Pivot………………… 30235
26.
5/8
" Shim (4)………………………….. 30112
27. Grease Fitting………………………… F-100
28. Belt Tensioning Swing Arm…………. 30236
29.
1/2
" Lock Washer……………………. W-111-V
30. Flat Idler Pulley……………………….
30224
