Dixie Narco 90 Series - Accepts Coins and Will Vend, Then Rejects Coins But Will Continue to Free-Vend; Problem 1: Set Up Credit; Rejects coins

Page 37 of 72
REJECTS ALL GOOD COINS
Problem 1: The coin changer will not accept coins.
Put product in each column.
Follow the arrow WHICH IS THE DIRECTION OF FLOW OF THE ELECTRICAL
CURRENT. (See figure below)
DO THIS:
1. Make sure there is product in each column. The sold out lamps are off.
2. Follow the arrows from left to right.
3. a. Push vend motor switch - motor D - Vend Motor cycles.
b. Push vend motor switch - motor C - Vend motor does not cycle.
The problem is the vend motor switch and by-pass switch on motor C and/or motor D.
e. If the problem is not found, continue this procedure through motors B and A.
f. If the problem is not found, replace the vend relay.
g. If the problem is not found, the last component to check would be the coin changer.
