Dixie Narco DNCB 276 - Main Door Interior

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
MAIN DOOR INTERIOR
ITEM # DESCRIPTION PART NUMBER
1 Delivery Port (Large Port)
801,810,68x.x1
2 Delivery Port Spacer (Large Port)
W/A Trim Spacer 624,052,40x.x3
Right Side 624,050,64x.x3
Left Side 624,050,63x.x3
3 Port Stiffener
Wide / Narrow 624,050,03x.x3
4A Access Door (prior to 6506AX)
Wide / Narrow 805,700,89x.x1
4B Access Door (hinged) (0001-6506AX and higher)
Wide / Narrow 805,701,12x.x1
5 Hopper
Top 805,700,69x.x1
6 Door Rod
Wide 801,401,83x.x1
Narrow 801,401,84x.x1
7 Door Hinge
Top 801,305,14x.x1
Bottom 801,305,13x.x1
8 Cash Box W/A
624,052,80x.x3
9 Cash Box Coin Chute Assy.
624,052,70x.x3
10 Cash Box Shelf
Wide 805,700,66x.x1
11 Closure Strip
Wide / Narrow 609,050,14x.x3
12 Cover, Wire Plug
Wide / Narrow 624,050,67x.x3
13 "L" Profile Gasket
Wide 903,600,53x.x1
Narrow 903,600,54x.x1
14 Assy., Coin Return Cup
Wide / Narrow 624,052,30x.x3
15A Weld Assy. Coin Return Cup
Wide 624,050,30x.x3
15B Coin Return Cup Door
801,810,75x.x1
16 Lamp Bracket
Wide / Narrow 624,050,39x.x3
17 S3D Mounting Bracket
72" Wide / Narrow 624,050,72x.x3
79" Wide 624,050,73x.x3
18 Bracket, Door Switch
Wide / Narrow 604,051,28x.x3
19 Bill Validator Guard
Wide / Narrow 805,700,98x.x1
