NA (Note Acceptor Test)
DSP (Display Test)
VERS (Software Version)
VNDR (Vender Identification)
RTN (Return)
AUTO (Auto Testing)
A. Press & hold buttons 1 & 2 simultaneously to move through the menu from top to bottom.
B. Press select button 1 to move left or right in the menu, depending on the menu prompt on the
display.
ELECTRICAL PARTS AND FUNCTIONS
CORRECT CHANGE LAMP
Correct Change Lamp
The Correct Change Lamp is mounted in the Coin Insert Casting.
The Correct Change Lamp is controlled by the SIID Controller board and is "OFF" when coins are in the tubes of
the Coin Changer.
SELECT SWITCH
Select Switch
The Select Switch is located in the Select Panel behind the Select Button and is secured with two (2) screws.
The normally closed contact of the Select Switch is in the SIID Control Board and Vend Motor Coil Circuits. This
normally closed contact opens and the SIID Control Board Circuit completes the Vend Motor Coil circuit.
The normally open contact of the Select Switch has no function.
SOLD OUT SWITCHES
The Sold Out Switch is located on the Front Mechanism Plate under the Vend Motor Cover.
The Sold Out Switch is the "snap in" type. To install, place the switch in position over the opening in the Front
Mechanism Plate, push in and at the same time, slide to the right.
Vend Sold Out Switch
