Dixie Narco DNCB 368 - Electronic Components

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
ELECTRONIC COMPONENTS / MISC. LABELS
ITEM DESCRIPTION
DNCB 600E DNCB 501E DNCB 276E
79" Wide 72" Wide 72" Narrow
1 Control Board
S3D 804,915,10x.x1 804,915,10x.x1 804,915,10x.x1
SIID 804,911,83x.x1 804,911,83x.x1 804,911,83x.x1
2 Display Board Assy.
804,914,11x.x1 804,914,11x.x1 804,914,11x.x1
3 SIID Control Board Curtain
801,903,38x.x1 801,903,38x.x1 801,903,38x.x1
4 Door Switch
804,100,77x.x1 804,100,77x.x1 804,100,77x.x1
5 Controller Software (Eprom)
SIID 804,911,390.51-B 804,911,390.51-B 804,911,390.51-B
SIID / S3D EVS 2.2 804,911,390.81-A 804,911,390.81-A 804,911,390.81-A
6 Transformer
804,909,80x.x1 804,909,80x.x1 804,909,80x.x1
7 Fuses
1.6 Amp Slow Blow Fuse 804,800,71x.x1 804,800,71x.x1 804,800,71x.x1
6 Amp Fast Acting Fuse 804,901,93x.x1 804,901,93x.x1 804,901,93x.x1
1 Amp Slow Blow Fuse (SIID Only) 804,800,72x.x1 804,800,72x.x1 804,800,72x.x1
8 Display Segment Character
14 Segment 804,912,79x.x1 804,912,79x.x1 804,912,79x.x1
9 Wiring Diagram
SIID-9/9 803,855,73x.x1 803,855,73x.x1 NA
S3D-9/9 803,855,72x.x1 803,855,72x.x1 NA
S3D-13/9 with Sold-Out Lights 803,854,41x.x1 803,854,41x.x1 NA
S3D-13/9 without Sold-Out Lights 803,854,39x.x1 803,854,39x.x1 NA
S3D-9/9 without Sold-Out Lights 803,856,34x.x1 803,856,34x.x1 NA
S3D-9/9 with Sold-Out Lights 803,856,35x.x1 803,856,35x.x1 NA
S3D-9/7 without Sold-Out Lights NA NA 803,856,36x.x1
S3D-9/7 with Sold-Out Lights NA NA 803,856,37x.x1
10 Labels
Press Selection to Display Price 903,835,15x.x1 903,835,15x.x1 903,835,15x.x1
Press Selection to Display Price or Sold-Out 803,902,55x.x1 803,902,55x.x1 803,902,55x.x1
4-Button Programming Space-to-Sales Options 803,849,04x.x1 803,849,04x.x1 803,849,04x.x1
Price 903,828,82x.x1 903,828,82x.x1 903,828,82x.x1
Coin Mech 903,901,30x.x1 903,901,30x.x1 903,901,30x.x1
4 Button Programming 903,854,06x.x1 903,854,06x.x1 903,854,06x.x1
Warning: Do Not Tilt 803,843,64x.x1 803,843,64x.x1 803,843,64x.x1
134A Removable Substance 903,833,54x.x1 903,833,54x.x1 903,833,54x.x1
Money Removed Daily 903,805,70x.x1 903,805,70x.x1 903,805,70x.x1
Coke Validator Opening Instructions (Domestic) 803,822,94x.x1 803,822,94x.x1 803,822,94x.x1
Power Disconnect 803,835,98x.x1 803,835,98x.x1 803,835,98x.x1
Loading Instructions 903,837,07x.x1 903,837,07x.x1 903,837,07x.x1
Package Set-Up Guide 803,849,11x.x1 803,849,11x.x1 803,849,11x.x1
Gate - Caution 803,855,82x.x1 803,855,82x.x1 803,855,82x.x1
Power Supply Cord Label 803,834,65x.x1 803,834,65x.x1 803,834,65x.x1
Skid Removal 903,828,70x.x1 903,828,70x.x1 903,828,70x.x1
