Dixie Narco DNCB 440 - Select Panel; Coin Insert Panel

COCA
-
COLA MARKETING MACHINE SERVICE MANUAL
D
IXIE
-
NARCO, INC.
SELECT PANEL / COIN INSERT PANEL
ITEM # DESCRIPTION PART NUMBER
1A Select Panel Assy.
12 Select 624,051,80x.x3
8 Select 624,051,90x.x3
1B Select Panel Stud Assy.
12 Select 624,052,00x.x3
8 Select 624,052,10x.x3
2 Select Button
801,810,62x.x1
3 Select Button Retainer
.063x1
9
/
16
x14
13
/
16
624,050,12x.x3
4 Select Button Stop
.063x2.301x14.813 805,700,58x.x1
5 Select Switch SIID
804,100,74x.x1
6 Switch Insulator
801,805,92x.x1
7A Coin Insert Panel Weld Assembly
Domestic 624,053,90x.x3
Export 624,054,00x.x3
7B Coin Insert Panel Stud Assembly
Domestic 624,051,30x.x3
Export 624,051,40x.x3
8A POS Window Lens
801,810,69x.x1
8B POS Window Gasket
802,001,29x.x1
8C POS Window Backup Plate
.045x5.422x13.332 624,050,48x.x3
8D Coin Insert POS Card
Thirsty 803,853,87x.x1
9 Feature Button
Retainer, Feature Button 805,700,93x.x1
Stop, Feature Button 805,700,94x.x1
Mars Validator Mounting Plate 624,050,56x.x3
Filler Plate 624,050,57x.x3
Feature Button Assy. 624,051,50x.x3
Feature Button Plate Assy. 624,051,60x.x3
10A Display Lens
801,810,67x.x1
10B Display Lens Gasket
802,001,28x.x1
10C Display Visibility Gasket
802,001,31x.x1
11A Validator Filler Plate
360,050,72x.x3
