CARE AND MAINTENANCE
Deck Removal - Zeeter 36”
1. Place cut height lever in lowest cut position.
2. Loosen nut on belt idler shock mount until belt can be
removed from electric clutch pulley on the bottom of
the engine. Refer to illustration.
3. Remove hair pin cotter and washer from one end of
deck support cross shaft. Note location of remaining
shim washers used between chassis and mower deck
pan arms. Slide shaft from chassis and mower deck.
4. Remove hair pin cotter and washer from each deck
adjustment rod. Carefully push each link toward the
outside of the mower chassis. At this point, deck will
drop down.
5. Carefully raise and support front of chassis. Slide
mower deck to either side for removal. (Reverse
procedure to reinstall deck assembly.)
