41
CARE AND MAINTENANCE
CAUTION
Stop engine, remove key and set
parking brake before attempting to
adjust the rear chain.
REAR CHAIN ADJUSTMENT:
Proper tension for the rear chains is accomplished through
the use of an adjuster located at mid-point of each rear chain.
To adjust, tighten the nut on top of the rubber spring until the
chain has approximately 1/4” movement up and down when
measured at mid-point. Refer to illustration.
NOTE: Adjust rear drive chains after first 10 hours of
use and every 40 hours thereafter.
NOTE: DO NOT OVERTIGHTEN CHAIN!
Maintenance:
Periodically remove any build-up of grass, mud or other
debris from both the spring loaded roller and the upper guide
rod. The use of a high quality chain lubricant is recom-
mended.
