MAINTENANCE
Dixon-39
Fuel Filter
Replace the line-mounted fuel lter every 100 hours
(once per season) or more regularly if it is clogged.
Replace the lter as follows:
1. Move the hose clamps away from the lter. Use
at-nosed pliers.
2. Pull the lter loose from the hose ends.
3. Push the new lter into the hose ends. Position the
lter with the “FLOW” arrow pointing up toward the
fuel pump. If necessary, a soap solution can be
applied to the lter ends to ease mounting.
4. Move the hose clamps back toward the lter.
Fuel Pump Air Filter
Regularly check that the fuel pump’s air lter is free
from dirt.
Remove the screws and open the pump, no hoses
need be removed.
The lter can be cleaned with a brush if necessary.
Replace the lter on the console.
8011-468
Fuel lter
8009-147
The fuel pump’s air lter
