MAINTENANCE
Dixon-45
Anti-Scalp Rollers
Anti-scalp rollers are properly adjusted when they
are just slightly off of the ground when the deck is at
the desired cutting height in the operating position.
Anti-scalp rollers then keep the deck in the proper
position to help prevent scalping in most terrain
conditions.
IMPORTANT INFORMATION
Adjust anti-scalp rollers with the mower on a
at level surface.
IMPORTANT INFORMATION
The anti-scalp rollers must not be used for
gauge wheels or the roller and deck may be
damaged.
Anti-scalp rollers
The anti-scalp rollers can be set in three positions:
• Upper position 1½ to 3" (38 to 76 mm) grass.
• Middle position 3" to 4½" (76 to 114 mm) grass.
• Lower position 4½" to 6" (114 to 152 mm) grass.
The rollers should be approximately ¼" (6.5 mm) from
ground. Do not adjust the rollers to support the deck.
