A3/A3Pro

User Manual

Mounting the PUM Module

Mount the PMU module to an unobstructed position on the bottom of the aircraft’s upper plate for heat

dissipation.

Mounting the IMU Pro Module

Mount the IMU Pro module with the Orientation Arrow pointing forward, backward, to the left or to

the right. Make sure the module is parallel to the aircraft and then x it onto the aircraft with double-

faced adhesive tape. Congure the parameters in DJI Assistant 2 and select the direction in which you

mounted the Flight Controller. We recommend mounting the Flight Controller with the Orientation Arrow

pointing forward..

PMU

Other manuals for dji A3

Questions and Answers:

Need help?

Do you have a question about the dji A3 and is the answer not in the manual?

Flight Performance

hovering accuracy (vertical)	±0.5 m
hovering accuracy (horizontal)	±2 m
max wind resistance	10 m/s
max yaw angular velocity	150°/s
max pitch angle	35°
max ascent velocity	6 m/s
max descent velocity	6 m/s

Power and Environment

power consumption	Max 21 W (Typical Value: 0.41 A @ 51 V)
operating temperature	14° to 113° F (-10° to 45° C)
