Overview
1. Antennas
2. Antenna Ports
3. DJI CrystalSky Monitor
4. Fans
5. External Power Port
6. Reserved Antenna Ports
7. Ethernet Port
8. USB Port
9. Intelligent Batteries
10. Power Button
11. Battery Level Indicators
12. Working Status Indicators
13. Antenna Storage Position
Indicators
Rx1: Type 1 receiver status indicator
Rx2: Type 2 receiver status indicator
Rx3: Type 3 receiver status indicator
Drone: UAV information capture indicator
Link: Monitor connection status indicator
MB: Processor module status indicator
Rx1
Rx2
Rx3
Drone
Link
MB
