Rx1: Type 1 receiver status indicator
Indicator Description
Solid green Functioning normally.
Solid red Functioning abnormally.
Rx2: Type 2 receiver status indicator
Indicator Description
Solid green Functioning normally.
Solid red Functioning abnormally.
Rx3: Type 3 receiver status indicator
Indicator Description
Solid green Functioning normally.
Solid red Functioning abnormally.
Drone: UAV information capture indicator
Indicator Description
Green blinking
UAV detected, green LED blinking indicates UAV information
reception.**
Off No UAV information received.
** The UAV number is the reported number from the background. The same UAV serial number
in a short time is regarded as one.
Link: Monitor connection status indicator
This is used to indicate the connection status between the processor and monitor.
Indicator Description
Solid green Connected normally and communicating with the monitor.
Solid red Disconnected from the monitor.
MB: Processor module status indicator
This is used to indicate the processor’s working status.
Indicator Description
Green blinking Functioning normally or rmware updated successfully.
Yellow blinking Checking consistency when powered on or updating rmware.
Red blinking Firmware update failed.
Solid on/off Functioning abnormally.
