6
Working Environment
Operating Temperature Range -4° to 104° F (-20° to 40° C)
Recommended Storage
Temperature
71.6° to 86° F (22°C to 30° C)
Relative Humidity 5% to 100%
Absolute Humidity 1 g/m
3
to 30 g/m
3
Atmospheric Pressure 70 kPa to 106 kPa
Physical Specications
Dimensions (without the Antennas) 405 mm (D) × 327 mm (W) × 175 mm (H)
Weight 8.5 kg
Supported Aircraft
Phantom series
Inspire series
Mavic series
Spark series
Battery****
Model TB50-4280mAh-22.8V
Capacity 4280 mAh
Voltage 22.8 V
Battery Type LiPo 6S
Energy 97.58 Wh
Net Weight 515 g
Charging Temperature 41° to 104° F (5° to 40° C)
Operating Temperature -4° to 104° F (-20° to 40° C)
Max Charging Power 180 W
*** Tested at room temperature (25° C).
**** Download the detailed
Intelligent Flight Battery Safety Guidelines
at:
https://www.dji.com/inspire-2/info#downloads
