dji FPV REMOTE CONTROLLER - Specifications

EN
5
5. Activation
When the remote controller is powered on, connect the USB-C port to your computer and
run DJI ASSISTANT
TM
2 for activation.
Download DJI Assistant 2 at https://www.dji.com/fpv/downloads
Specications
Remote Controller
Weight
765 g
Operating Frequency
5.725 - 5.850 GHz
Max. Transmission Distance
(unobstructed, free of interference)
FCC/SRRC: 4 km; CE: 0.7 km
Transmitter Power (EIRP)
FCC: <30 dBm; CE: <14 dBm; SRRC: <19 dBm
Operating Current/Voltage
0.6 A @ 7.6 V
Operating Temperature
0° to 40° C (32° to 104° F)
Charging Temperature 5° to 40° C (41° to 104° F)
Remote Controller Intelligent Battery (WB37-4920mAh-7.6V)
Battery Type LiPo 2S
Capacity 4920 mAh
Voltage 7.6 V
Energy 37.39 Wh
If you need to use the DJI FPV Goggles and remote controller together, the air unit must be
linked to the goggles before the remote controller.
* When ready to link, the devices will give the following indication:
Air unit: the linking status indicator turns solid red.
Remote controller: the remote controller beeps continually and the status indicator blinks blue.
6. Linking
1. Power on the air unit and the DJI FPV Remote Controller.
2. Press the link button on the air unit, and then press the record button, C button, and
right dial on the remote controller simultaneously.*
3. Both the linking status indicators turn solid green when successfully linked.
